enclosed pro

Designed for ultimate indoor skydiving.

maximum performance

Pro series of tunnels have top-of-the-line specs to satisfy the needs of professionals. The size and performance of our Pro wind tunnels are in line with the highest international standards.

At the same time, it is also a perfect venue for beginners who are looking for a highlight. The spacious flight area combined with smooth and soft airflow will impress any adventure seeker.

competition standard

Indoor skydiving has been growing as a sport, and since 2015 regular World Championships are organised.

Through years of research and development, we have designed technology that has become the top pick among skydivers and can easily qualify for competitions.

AERODIUM Model R4 was the host of the 2018 FAI World Championship in Bahrain. It accommodated all main disciplines of indoor skydiving.

skydiving training

AERODIUM Pro line models have the power and quality of the airflow that is needed to unleash new levels of flying speed, precision, and creativity.

  • Skydivers. Recirculation tunnels are weather independent, therefore, skydivers can polish their flying skills at any time.
  • Paratroopers. The power of recirculation tunnels allows military skydivers to practice skydiving with full equipment and become better prepared for combat situations.
  • Bodyfliers. With development of wind tunnels bodyflight has become a new sport category in itself.

premium design

Pro series tunnel is the best fit for any high-end location, where design and WOW factors are crucial.

  • Conceptual idea. In the design of flight chamber we aimed to emphasize the extraordinary aspect of levitation.
  • Special effects. AERODIUM recirculation tunnels are equiped with various technologies to create a show effect.
  • Premium details. Flying is a premium activity, therefore, we use premium materials to enhance this experience.

SIGNATURE FEATURES

Pro series models have top safety and entertainment features.

  • B.A.S.E. chamber. An optional feature for experienced flyers simulating a B.A.S.E. jump exit in a controlled environment at the top of the flight chamber.
  • Impact Reduction System. Our latest invention turns the safety net at the bottom of the flight chamber into a trampoline as impact absorption surface in cases of high falls.
  • Fly Wheel Technology. A heavy steel hub for fan blades ensures higher air inertia in case of power outage and provides flyers with sufficient airflow for a safe landing.

designed for

Pro training

Our wind tunnels are capable of providing up to 300 km/h air velocity. The air is smooth in every corner of the tunnel enabling performers to perfect flying skills and feel as close to real skydiving as possible. Perform static head-down with the industry’s highest air flow speed offered. Enclosed Pro wind tunnels perfectly fit all requirements for professional indoor skydiver training and the growing Pro skydiver community around the world.

Shows and competitions

Acrobatic shows for spectators. Sound and Light, special effects, and themed accessories are available. Great visibility with a glass flying chamber of up to 11 meters.
R4 model allows organizing large-scale indoor skydiving competitions in all major disciplines. “Gravity” (R4 model by AERODIUM) in Bahrain hosted the World Cup of Indoor Skydiving in 2018.

Experience flights

Anyone can fly starting at age 4! Flying in a wind tunnel or skydiving simulator is safe, no previous experience is needed. This unique activity is an exciting experience for everybody and has to be included in everyone’s bucket list.

Military training

Paratroopers and special forces can train essential skills for skydiving in any weather conditions. Pro tunnels not only ensure efficient training of movements, coordination, and teamwork but also present a safe and secure environment.

target location

Indoor skydiving centres

Create a unique sports destination for extreme sports lovers. It can be a standalone location or part of a larger entertainment centre. Aerodium team of engineers and architects will help you design a real masterpiece, where technology meets modern lifestyle.

High-end shopping malls

In recent years shopping centres have been looking for ways how to distinguish themselves and how to increase footfall. With Covid-19 changing purchasing habits of people, shopping malls can choose to build a wind tunnel to attract people to their location.

Military training premises

A closed facility at an army base allows training at any time, day or night, and coordinating different movements without civilians watching. A large tunnel will provide enough capacity to systematically train soldiers of various ranks.

compare

R3

From €2.65M
Indicative price on franchise terms, EUR

R4

From €3.25M
Indicative price on franchise terms, EUR

R5

From €3.95M
Indicative price on franchise terms, EUR

Designed for:

Flying experience
Events
Shows
Movies

Key specs:

Maximum amount of simultaneous flyers
Maximum amount of simultaneous flyers
1 + instructor
4
1 + instructor
6
1 + instructor
8
3.6 m / 12 ft
3.6 m / 12 ft
4.3 m / 14.1 ft
4.3 m / 14.1 ft
5.2 m / 17.1 ft
5.2 m / 17.1 ft
265 km/h / 166 mph
265 km/h / 166 mph
Up to 300 km/h / 186 mph
Up to 300 km/h / 186 mph
Up to 300 km/h / 186 mph
Up to 300 km/h / 186 mph
Noise emission in the spectator area
Noise emission in the spectator area
63 dBA
63 dBA
63 dBA
63 dBA
63 dBA
63 dBA
350 kW
350 kW
600 kW
600 kW
650 kW
650 kW
1500 kVA, 3 phase
1500 kVA, 3 phase
2000 kVA, 3 phase
2000 kVA, 3 phase
3000 kVA, 3 phase
3000 kVA, 3 phase
16 weeks
16 weeks
16 weeks
16 weeks
16 weeks
16 weeks
Underground integration
Underground integration
Underground integration
Underground integration
Underground integration
Underground integration

Overall dimensions:

22.2 m / 72.8 ft
22.2 m / 72.8 ft
29 m / 95.14 ft
29 m / 95.14 ft
31.5 m / 103.3 ft
31.5 m / 103.3 ft
8.8 x 17.6 m / 28.9 x 57.7 ft
8.8 x 17.6 m / 28.9 x 57.7 ft
13.8 x 27.2 m / 45.2 x 89.1 ft
13.8 x 27.2 m / 45.2 x 89.1 ft
17.1 x 30.6 m / 56.1 x 100.4 ft
17.1 x 30.6 m / 56.1 x 100.4 ft
12.5 m / 41 ft
12.5 m / 41 ft
16 m / 52.5 ft
16 m / 52.5 ft
15 m / 49.2 ft
15 m / 49.2 ft
5 - 8 m / 16.4 - 26.2 ft
5 - 8 m / 16.4 - 26.2 ft
8 - 11 m / 26.2 - 36 ft
8 - 11 m / 26.2 - 36 ft
6 - 9 m / 19.7 - 29.5 ft
6 - 9 m / 19.7 - 29.5 ft
Not ideal but will get the job done Great fit! Not suitable

compare

R3

From €2.65M
Designed for:
Flying experience
Events
Shows
Movies
Key specs:
1 + instructor
4
3.6 m / 12 ft
3.6 m / 12 ft
265 km/h / 166 mph
265 km/h / 166 mph
63 dBA
63 dBA
350 kW
350 kW
1500 kVA, 3 phase
1500 kVA, 3 phase
16 weeks
16 weeks
Underground integration
Underground integration
Overall dimensions:
22.2 m / 72.8 ft
22.2 m / 72.8 ft
8.8 x 17.6 m / 28.9 x 57.7 ft
8.8 x 17.6 m / 28.9 x 57.7 ft
12.5 m / 41 ft
12.5 m / 41 ft
5 - 8 m / 16.4 - 26.2 ft
5 - 8 m / 16.4 - 26.2 ft

R4

From €3.25M
Designed for:
Flying experience
Events
Shows
Movies
Key specs:
1 + instructor
6
4.3 m / 14.1 ft
4.3 m / 14.1 ft
Up to 300 km/h / 186 mph
Up to 300 km/h / 186 mph
63 dBA
63 dBA
600 kW
600 kW
2000 kVA, 3 phase
2000 kVA, 3 phase
16 weeks
16 weeks
Underground integration
Underground integration
Overall dimensions:
29 m / 95.14 ft
29 m / 95.14 ft
13.8 x 27.2 m / 45.2 x 89.1 ft
13.8 x 27.2 m / 45.2 x 89.1 ft
16 m / 52.5 ft
16 m / 52.5 ft
8 - 11 m / 26.2 - 36 ft
8 - 11 m / 26.2 - 36 ft

R5

From €3.95M
Designed for:
Flying experience
Events
Shows
Movies
Key specs:
1 + instructor
8
5.2 m / 17.1 ft
5.2 m / 17.1 ft
Up to 300 km/h / 186 mph
Up to 300 km/h / 186 mph
63 dBA
63 dBA
650 kW
650 kW
3000 kVA, 3 phase
3000 kVA, 3 phase
16 weeks
16 weeks
Underground integration
Underground integration
Overall dimensions:
31.5 m / 103.3 ft
31.5 m / 103.3 ft
17.1 x 30.6 m / 56.1 x 100.4 ft
17.1 x 30.6 m / 56.1 x 100.4 ft
15 m / 49.2 ft
15 m / 49.2 ft
6 - 9 m / 19.7 - 29.5 ft
6 - 9 m / 19.7 - 29.5 ft

TIMELINE, AND RESPONSIBILITIES

Months123456789101112
AerodiumTunnel launch
Tunnel design, engineering, and adaptation
Tunnel equipment manufacturing
Tunnel equipment delivery FOB (i)
Tunnel installation and testing
Technical and business training
Client
Building design and engineering
Construction permits
Local construction
Staff hiring
Pre-launch marketing
Local operation permits

This timeline is approximate and may vary by project.

REFERENCES

SEE PROJECTS

FAQ

What is the capacity of Aerodium vertical wind tunnels?

Vertical wind tunnels have a maximum capacity of 25 flights per hour with a flight time of 2 minutes per person.

Passive Capacity: Spectators love watching people fly in wind tunnels, including acrobatic tricks by pro flyers. The entertainment value of this attraction makes it the perfect anchor for alternative revenue sources like food and beverage, retail products, sponsorship opportunities, and corporate and competitive events.

Why are permanent installations more expensive than open-air?

Classic permanent installations require large-scale building constructions, often involving excavations to accommodate return air chambers. Everything together makes a rather massive construction with high costs. In contrast, open-air wind tunnels do not need a foundation and can be placed on any even surface, such as a parking lot.

Franchise or outright ownership?

You have a choice between both – franchising and outright ownership. With outright ownership, you have more freedom to operate the business as you wish. The downside is that it will require a much deeper involvement and building your own brand. In the franchise option, you would get a full support package and the renowned Aerodium branding, which both will facilitate running the business.

How big is the flight zone?

The size of a tunnel is measured most commonly by the diameter of the flight chamber. The larger the diameter, the more people can fly simultaneously. The most common size is 14 ft (4.3 m), which is required by pro skydivers and for competitions. However, recently smaller sized tunnels are becoming increasingly popular, as they are more efficient for training beginners and more affordable for the general public. But generally, wind tunnels from 2m up to 9.8m in diameter can be found.
